Opzoon PT-3750E-52T
Opzoon PT-3750E-52T
-
Opzoon PT-3750E-52T
Configuration
PT-3750E-52T:48 x 10/100/1000 BASE-T + 4 x 10 GbE SFP+
Capability
Up to 176Gbps throughput
Up to 130.9Mpps forwarding
Support High port density for 10GbE
Wire-speed L2/L3 forwarding
Fast Ethernet ring network protection technology-OPRP
Complete IPv6 features
Multi-service and Security Capacity
Complete multicast solutions for IPTV, Voice, and Data-distribution
Support IEEE802.1x flow control
Up to 8 queues per port for QoS function
Effective MAC security and hardware ACL
Support Anti-BT, IP Conflict Prevention, Trust View, and Guest VLAN
Comprehensive ARP attacking prevention
MPLS Multi-VRF reduces investment of MPLS VPN deployment
Lite Layer 3
Provides IP routing features as RIPv1/v2, OSPF, BGP, and ISISv4
Support VRRP and GR(Graceful Restart)
IPv4/IPv6 Tunneling
Easy Management
Support SNMPv1/v2/v3
Support WEB, SSH, Syslog, TELNET, and SHELL
CUP protection and hardware/software watchdog -
Opzoon PT-3750E-52T
Access Switches PT-3750E-28T PT-3750E-52T PT-3750E-28F PT-3750E-28P Ports 24x 10/100/1000 BASE-T 48 10/100/1000 BASE-T 24 x GbE SFP 24x 10/100/1000 BASE-T Uplink Interface 4 x 10 GbE SFP+ 4 x 10 GbE SFP+ 4 x 10 GbE SFP+ 4 x 10 GbE SFP+ PoE - - - 802.3af standard (max 15.4w)
802.3at standard (max 30w)Switching Capacity 128Gbps 176Gbps 128Gbps 128Gbps Package Forwarding Rate 95.2Mpps 130.9Mpps 95.2Mpps 95.2Mpps Power Consumption ≤65W ≤90W ≤90W ≤530W(PoE) Jumbo frame 12KB Dimension(W*H*D mm) 440*43.4*318 440*43.4*396 440*43.4*318 440*43.4*318 Working Humidity 5%~95% Noncondensing Working Temperatur 0°C~50°C Storage Temperature -40°C~70° Power Supply AC:100-240V, 50-60 Hz -
Opzoon PT-3750E-52T
Ulotki:
Opzoon seria PT-3750E
