Opzoon PT-2960G-52T
Opzoon PT-2960G-52T
-
Opzoon PT-2960G-52T
Configuration
PT-2960G-52T：48 x 10/100/1000 BASE-T + 4 x GbE SFP
Capability
Up to 104Gbps throughput
Up to 77.4Mpps forwarding
Support High port density for 1GbE
Wire-speed L2/L3 forwarding
Support Q-in-Q VLAN
Link failure detected by UDLD
Security
Complete ARP attack protection
Support IEEE802.1x flow control
Effective MAC security and hardware ACL
Support Anti-BT, IP Conflict Prevention, Trust View, and Guest VLAN
Quality of Service
Up to 8 queues per port
802.1p based classification
DSCP based classification and remarking
Strict priority queuing
ACL based Policing
Rate limiting
Easy Management
Support SNMPv1/v2/v3
Support WEB, SSH, Syslog, TELNET, and SHELL
Real time monitoring, dynamic alert, and automatic adjustment for power supplies and fans -
Opzoon PT-2960G-52T
Access Switches PT-2960G-10T PT-2960G-28T PT-2960G-52T PT-2960G-28P Ports 8 x 10/100 BASE-T 24x 10/100 BASE-T 48 10/100 BASE-T 24x 10/100 BASE-T Uplink Interface 2 x GbE Combo 2 x GbE Combo 4 x GbE SFP 2 x GbE Combo PoE - - - 802.3af standard (max 15.4w)
802.3at standard (max 30w)Switching Capacity 20Gbps 56Gbps 104Gbps 56Gbps Package Forwarding Rate 14.9Mpps 41.7Mpps 77.4Mpps 41.7Mpps Power Consumption ≤25W 60W ≤90W ≤450W(PoE) Jumbo frame 12KB Dimension(W*H*D mm) 330*43.4*200 440*43.4*250 440*43.4*396 440*43.4*250 Working Humidity 5%～95% Noncondensing Working Temperatur 0°C～50°C Storage Temperature -40°C～70° Power Supply AC:100-240V, 50-60 Hz -
Opzoon PT-2960G-52T
Ulotki:
Opzoon seria 2960G
