Opzoon PT-2960G-10T

StartOfertaINFRASTRUKTURA ITPRZEŁĄCZNIKI SIECIOWEOpzoon PT-2960G-10T

Opzoon PT-2960G-10T


  • Opzoon PT-2960G-10T

    Configuration
    PT-2960G-10T：8 x 10/100/1000 BASE-T + 2 x GbE Combo
    Capability
    Up to 20Gbps throughput
    Up to 14.9Mpps forwarding
    Support High port density for 1GbE
    Wire-speed L2/L3 forwarding
    Support Q-in-Q VLAN
    Link failure detected by UDLD
    Security
    Complete ARP attack protection
    Support IEEE802.1x flow control
    Effective MAC security and hardware ACL
    Support Anti-BT, IP Conflict Prevention, Trust View, and Guest VLAN
    Quality of Service
    Up to 8 queues per port
    802.1p based classification
    DSCP based classification and remarking
    Strict priority queuing
    ACL based Policing
    Rate limiting
    Easy Management
    Support SNMPv1/v2/v3
    Support WEB, SSH, Syslog, TELNET, and SHELL
    Real time monitoring, dynamic alert, and automatic adjustment for power supplies and fans

  • Opzoon PT-2960G-10T
    Access Switches PT-2960G-10T PT-2960G-28T PT-2960G-52T PT-2960G-28P
    Ports 8 x 10/100 BASE-T 24x 10/100 BASE-T 48 10/100 BASE-T 24x 10/100 BASE-T
    Uplink Interface 2 x GbE Combo 2 x GbE Combo 4 x GbE SFP 2 x GbE Combo
    PoE - - - 802.3af standard (max 15.4w)
    802.3at standard (max 30w)
    Switching Capacity 20Gbps 56Gbps 104Gbps 56Gbps
    Package Forwarding Rate 14.9Mpps 41.7Mpps 77.4Mpps 41.7Mpps
    Power Consumption ≤25W 60W ≤90W ≤450W(PoE)
    Jumbo frame 12KB
    Dimension(W*H*D mm) 330*43.4*200 440*43.4*250 440*43.4*396 440*43.4*250
    Working Humidity 5%～95% Noncondensing
    Working Temperatur 0°C～50°C
    Storage Temperature -40°C～70°
    Power Supply AC:100-240V, 50-60 Hz
  • Opzoon PT-2960G-10T

    Ulotki:
    Opzoon seria PT-2960G
