Opzoon PT-2960-10T

Opzoon PT-2960-10T


  • Opzoon PT-2960-10T

    Configuration
    8 x 10/100 BASE-T + 2 x GbE Combo
    Wydajność:
    -Up to 5.6Gbps throughput
    -Up to 4.2Mpps forwarding
    - Support High port density for 1GbE
    - Wire-speed L2/L3 forwarding
    - Support Q-in-Q VLAN
    Advanced Security
    - Complete ARP attack protection
    - IEEE802.1x flow control
    - Effective MAC security and hardware ACL
    - Support Anti-BT, IP Conflict Prevention, Trust View, and Guest VLAN
    Quality of Service
    - Up to 4 queues per port
    - 802.1p based classification
    - DSCP based classification and remarking
    - Strict priority queuing
    - ACL based Policing
    - Rate limiting
    Easy Management
    - Support SNMPv1/v2/v3
    - Support WEB, SSH, Syslog, TELNET, and SHELL

  • Opzoon PT-2960-10T
    Access Switches PT-2960-10T PT-2960-26T PT-2960-52T PT-2960-26P PT-2960-50P
    Ports 8 x 10/100 BASE-T 24x 10/100 BASE-T 48 10/100 BASE-T 24x 10/100 BASE-T 48 10/100 BASE-T
    Uplink Interface 2 x GbE Combo 2 x GbE Combo 4 x GbE SFP 2 x GbE Combo 2 x GbE Combo
    PoE - - - 802.3af standard (max 15.4w) 802.3af standard (max 15.4w)
    Switching Capacity 5.6Gbps 8.8Gbps 17.6Gbps 8.8Gbps 13.6Gbps
    Package Forwarding Rate 4.2Mpps 6.5Mpps 13.1Mpps 6.5Mpps 10.1Mpps
    Power Consumption ≤13W 15W ≤65 ≤240(PoE) ≤501(PoE)
    Jumbo frame 10KB
    Dimension(W*H*D mm) 330*43.4*200 440*43.4*250 440*43.4*250 440*43.4*318 440*43.4*396
    Working Humidity 5%~95% Noncondensing
    Working Temperatur 0°C~50°C
    Storage Temperature -40°C~70°
    Power Supply AC:100-240V, 50-60 Hz
  • Opzoon PT-2960-10T

    Ulotki:
    Opzoon seria PT-2960
